Diesel Generator MQ DCA25 25kVA Single/Three phase super silent - $26,266 (santa rosa)
condition:
new
engine hours (total):
make / manufacturer:
Multiquip aka MQ Power
model name / number:
DCA25SSIU4F
size / dimensions:
71L x 36W x 35H 1797 lbs dry
QR Code Link to This Post
DCA25SSIU4F on a skid no trailer $26,266.46
DCA25SSIU4F on a trailer TRLR25US with a 2 inch ball hitch $ 28,368.59.
NEW. Never used. All 100% excellent condition, running 100%, producing 100% power in all single and three phases. Brand new units ready to roll.
Call Mike 707-332-0703 or text
The DCA25SSIU4F offers a prime rating of 20 kW (25 kVA) and a standby rating of 22 kW (27.5 kVA). Our patented open delta generator winding provides precise voltage control, allowing superior motor starting capability. An electronic governor maintains frequency to ± 0.25% from no load to full load. It features an auto start stop that allows the generator to start from a remote location. The unit features an e-coat and powder-coated, weatherproof steel housing that allows a substantially low operating noise level of 65 dB(A). A comprehensive analog control panel provides instrumentation including AC ammeter, AC voltmeter, frequency meter, AC circuit breaker, engine gauges and much more.
Unit Specifications
Prime Rating 20 kW 25 kVA
Standby Rating 22 kW 27.5 kVA
Generator RPM 1800
Voltage - Three Phase 208, 220, 240, 416, 440, 480V Switchable
Voltage - Single Phase 120, 127, 139, 240, 254, 277V Switchable
Generator Design Revolving field, Self-ventilated, Drip-proof, Single bearing
Voltage Regulation (No Load to Full Load) ±0.5 %
Power Factor 0.8
Armature Connection Star with Neutral/ Zig Zag
Excitation Brushless with AVR
No. Poles 4-pole
Frequency 60 Hz
Frequency Regulation (steady state load) ±0.25 %
Sound Level (Full Load at 23 ft.) 65 dB(A)
Engine Specifications
Make/Model Isuzu / 4LE2T
Emissions EPA Tier 4 Final Certified and other
Starting System Electric
Design 4-cycle, water cooled, direct injection, turbocharged, EGR
Gross Engine Power Output 40.2 bhp 30 kW
Fuel Tank Capacity 41.7 gal 158 L
Fuel Consumption:
Full load 1.62 gph 6.12 lph
3/4 load 1.26 gph 4.77 lph
1/2 load 0.94 gph 3.57 lph
1/4 load 0.67 gph 2.52 lph
DEF Tank Capacity gal L
Coolant Capacity 2.3 gal 8.8 L
Oil Capacity 2.8 gal 10.5 L
Battery 12V 53Ah x 1
Notice: Features and equipment specifications are subject to change without notice.
OPTIONS:
Single axle trailer.
View Detailed specifications at (copy and paste)
http://www.multiquip.com/multiquip/pdfs/DCA25SSIU4F_Data_Sheet_DataId_252007_Version_3.pdf
CALL MIKE or TEXT 707-332-0703
Emergency Towable Diesel Generators Available Immediately in California.
We have a limited supply of Multiquip Heavy Duty Construction/Emergency Backup Diesel Generators for sale! Your authorized dealer is Mike McPherson call or text 707-332-0703
Due to the fires in Southern California Multiquip has a rapidly dwindling supply of brand new generators available immediately. Brand new models with zero hours. I have been an authorized dealer since 2005. The prices of these generators are the lowest in a decade. Please do not ask for additional discounts. This is the best price available nationwide. All units are on a limited sale. Call or text and place your order to secure your discounted prices 707-332-0703
MQ Power WhisperWatt Super-Silent Generators are built to withstand the toughest jobs no matter how challenging the application. Some of the features include a heavy-duty steel housing, an open delta winding design, and an automatic voltage regulator. Our generators range from 6 kW to 600 kVA and they provide unmatched reliability in portable power.
MQ Power WhisperWatt Super-Silent Single/Three-Phase generators provide reliable power to meet the most demanding requirements. They are designed and built to withstand tough environments at construction sites and provide dependable temporary power at entertainment venues and disaster recovery operations.
Offered by your authorized Multiquip Dealer Mike McPherson. Call or text 707-332-0703
Emergency Towable Diesel Generators Available Immediately in California.
Offered by your authorized Multiquip Dealer Mike McPherson. Call or text 707-332-0703
Buy it now. This is Multiquip's entire nationwide inventory. Once these are sold out prices will increase a minimum of ten percent, and the lead time will be four to sixteen weeks. Most units will not be replaced until May/June 2025, larger units will not be replaced until September 2025. Call or text Mike 707-332-0703
Generator Models pre-assembled and ready to pickup or ship:
DCA25SSIU4F on a skid no trailer $26,266.46.
On a trailer TRLR25US with a 2 inch ball hitch $ 28,368.59. Blow out sale! Price is as described, additional options are extra.
DCA45SSIU4F on a skid $36,983.52.
On a trailer TRLR45 with 2 inch ball hitch, your best price $ 41,583.47 ea. Price is as described, additional options are extra.
DCA-36SPXU4F $38,374.56, on trailer TRLR45 mounted with 2 inch ball hitch, your best price $42,974.51 ea.
DCA70SSIU4F on a skid $51,299.14, on trailer TRLR70US mounted with 2 inch ball hitch $ 57,265.94 ea.
Customizable Generators with available options:
We also have these emergency diesel generators for sale. The first price shown is a skid mount generator. Options shown are extra to be added to the skid mount price. Example DCA10SPXU4C $15,017.18 + optionable Battery Charger $320.54 = $15,337.72
Single Phase Models:
DCA10SPXU4C $15,017.18 + Trailer TRLRMPXF $2709.50 with extra 28 gallon tank built into trailer + 2 inch ball Hitch $70.00 + Spare Tire $362.88 + Battery Charger $320.54. Hot item. Good for RV, camping trailers and home backup. Super quiet clean power safe for computers.
DCA15SPXU4F $17,587.58 + Trailer TRLRMPXF $2,709.50 with extra 28 gallon tank built into trailer + 2 inch ball Hitch $70.00 + Spare Tire $362.88 + Battery Charger $320.54.
DCA20SPXU4F $26,786.59 + Trailer TRLR25US2 $2,032.13 + 2 Inch ball Hitch $70.00 + 1 set Camlocks $597.63 + Spare Tire $489.89 + Battery Charger $399.17. Hot item. Good for RV, camping trailers and home backup. Super quiet clean power, safe for computers.
DCA36SPXU4F $38,374.56 + Trailer TRLR45 $2,032.13 + 2 inch ball Hitch $70.00 + 1 set Camlocks $556.42 + Spare Tire $350.78 + Battery Charger $399.17. Hot item. Good for RV, camping trailers and home backup. Super quiet clean power, safe for computers.
Three Phase Switchable to Single Phase Models:
DCA25SSIU4F $26,266.00 + Trailer TRLR25US $2,032.19 +2 inch ball Hitch $70.00 + 1 set Camlocks $556.42 + Spare Tire $489.89 + Battery Charger $399.17. Hot item. Good for construction and business backup. Super quiet clean power safe for computers.
DCA40SSIK4F $32,586.62 + Trailer TRLR45USH $4,529.95 + 2 inch ball Hitch $70.00 + 1 set Camlocks $556.42 + Spare Tire $350.78 + Battery Charger $399.17. Hot item. Good for construction and business backup. Super quiet clean power safe for computers.
DCA45SSIU4F $36,983.52 + Trailer TRLR45H $4,529.90 + 2 inch ball Hitch $70.00 + 1 set Camlocks $556.42 + Spare Tire $350.78 + Battery Charger $399.17 + Power Balancer Kit MQPPB45I4F $5,712.00 . Hot item. Good for construction and business backup. Super quiet clean power safe for computers.
DCA70SSIU4F $51,299.14 + Trailer TRLR70US $5,896.80 + 2 inch ball Hitch $70.00+ 1 set Camlocks $556.42 + Spare Tire $393.12 + Battery Charger $399.17 + Power Balancer Kit MQPPBNK70I4F3 $4,771.20. Good for construction and business backup. Super quiet clean power safe for computers.
DCA125SSJU4F $67,701.31 + Trailer TRLR125US $7,983.36 + 2 5/16 inch ball or Pintel . Hitch $80.00 + 2 set Camlocks $1,064.48 + Spare Tire $429.40 + Battery Charger $399.17 + Power Balancer Kit MQPPBNK1254F3 $5,485.20. Good for construction and business backup. Super quiet clean power safe for computers.
DCA150SSJIU4F3 $89,988.19 + Trailer TRLR180EV $10,886.40 + 2 5/16 inch ball or Pintel Hitch $80.00 + 2 set Camlocks $1,064.48 + Spare Tire $501.98 + Battery Charger $1,197.50 + Power Balancer Kit MQPPBNK150I4F3 $5,485.20
DCA180SSJIU4F3 $96,538.18 + Trailer TRLR108EV $10,886.40 + 2 5/16 inch ball or Pintel Hitch $80.00 + 2 set Camlocks $1,064.48 + Spare Tire $501.98 + Battery Charger $1,197.50 + Power Balancer Kit MQPPBNK180J4F3 $6,804.00.
DCA220SSJIU4F3 $108,138.24 + Trailer TRLR220EV $14,261.18 + 2 5/16 inch ball or Pintel Hitch $80.00 + 2 set Camlocks $1,064.48 + Spare Tire $550.37 + Battery Charger $1,197.50 + Power Balancer Kit MQPPBNK220I4F3 $6938.40. Good for construction and business backup. Super quiet clean power safe for computers.
DCA220SSJIU4F3PB 220kVA with Parallel Basler $108,274.32
DCA300SSJU4F3 Series $138,662.50 + Trailer TRLR300EV $13,940.64 + 2 5/16 inch ball or Pintel Hitch $80.00 + 2 set Camlocks $1,06448 + Spare Tire $635.04 + Battery Charger $1,197.50 + Power Balancer Kit MQPPBNKJ4F3 $8,316.00. Good for construction and business backup. Super quiet clean power safe for computers.
DCA300SSJU4F3PB 300kVA with Parallel Basler $152,197.92
DCA400SSI4F3B $182,250.43 + Trailer TRLR400XF3DAE 3 Axles 350 Gallons Electric Brakes $23,345.28 + 2 5/16 inch ball or Pintel Hitch $80.00 + 3 set Camlocks $1,705.08 + Spare Tire $550.37 + Battery Charger $1,197.50 + Power Balancer Kit MQPPBNK400I4F3 $11,466.00.
DCA400SSI4F3BPB $199,257.41 400kVA with Parallel Basler Kit MQPDCS400P required
DCA600SSV4F3B $311,520.38 + Trailer TRLR600XFBP3E 3 Axles 600 gallons Electric Brakes $35,489.44 + 2 5/16 inch ball or Pintel Hitch $80.00 + 4 Set Camlocks $3,447.36 + Power Balancer Kit MQPPB600V4F $9,247.84 + Spare Tire $695.52 + Battery Charger $1,197.50.
DCA600SSV4F3PB $314,671.39 with Parallel Basler Kit MQPDCS600P required
Parallel Basler allow you to parallel the generator in series and add the power together. For example parrallel two DCA400kVA together it makes 800kVA and so on. Paralleling is usually done with the DCA200 thru DCA600. You can also use them in combination.
All units on sale. Call to secure your discounted prices. 707-332-0703
For detailed specifications visit https://www.multiquip.com/multiquip/super-silent.htm
