Diesel Generator DCA45SSIU4F Multiquip 45kVA - $36,983 (santa rosa)
condition:
new
make / manufacturer:
Multiquip
model name / number:
DCA45SSIU4F
size / dimensions:
83.86 L X 37.4 W X 61.02 H
QR Code Link to This Post
Description
MQ Power Model DCA45SSIU4F, Whisper Watt Series, prime rating 36kW (45 kVA) 60 Hz, Sound Enclosure, Isuzu 4LE2X, super silent, three phase and single phase switchable, diesel fueled, liquid cooled, 1800 RPM, electric start, Tier 4 final certified.
The patented open delta generator winding provides precise voltage control, allowing superior motor starting capability. An electronic governor maintains frequency to ± 0.25% from no load to full load. It features an auto start stop that allows the generator to start from a remote location. The unit features an e-coat and powder-coated, weatherproof steel housing that allows a substantially low operating noise level of 66 dB(A). A comprehensive analog control panel provides instrumentation including AC ammeter, AC voltmeter, frequency meter, AC circuit breaker, engine gauges and much more.
They are designed and built to withstand tough environments at construction sites and provide dependable temporary power at entertainment venues and disaster recovery operations. And to safeguard the environment, the WhisperWatt Super-Silent Generator features an integrated 24-hour fuel tank with a fluid containment system.
Dimensions 83.86 L x 37.4 W x 61.02 H. Weight dry 2337 lbs. Wet 2976 lbs.
Unit Specifications
Prime Rating 36 kW 45 kVA
Standby Rating 40 kW 50 kVA
Generator RPM 1800
Voltage – Single Phase 208, 220, 240, 416, 440, 480V Switchable
Voltage – Single Phase 120, 127, 139, 240, 254, 277V Switchable
Generator Design Revolving field, Self-ventilated, Drip-proof, Single bearing
Voltage Regulation (No Load to Full Load) ±0.5%
Power Factor 0.8
Armature Connection Star with Neutral/ Zig Zag
Excitation Brushles with AVR
No. Poles 4-pole
Frequency 60 Hz
Frequency Regulation (steady state load) ±0.25
Sound Level (Full Load at 23 ft.) 66 dB(A
Engine Specifications
Make/Model Isuzu / 4LE2X
Emissions EPA Tier 4 Final Certified
Starting System Electric
Design 4-cycle, water cooled, direct injection, turbocharged, charge air cooled and EGR
Gross Engine Power Output 65.7 bhp 49 kW
Fuel Tank Capacity 79.2 gal 300 L
Fuel Consumption:
Full load 2.93 gph 11.1 lph
3/4 load 2.20 gph 8.31 lph
1/2 load 1.60 gph 6.04 lph
1/4 load 1.04 gph 3.92 lph
DEF Tank Capacity N/A gal N/A L
Coolant Capacity 4.44 gal 16.8 L
Oil Capacity 3.2 gal 12.2 L
Battery 12V 72Ah x 1 included
TRLR45 is included with generator.
Trailer Specifications
Gross Vehicle Weight Rating (GVWR) 7,000 lb 3,175 kg
Gross Axle Weight Rating (GAWR) (ea.) 3,500 each lb 1,588 kg
Coupler Rating 3″ Pintle Eye (25,000 lb)
2″ Ball Coupler (10,000 lb)
2-5/16″ Ball Coupler (14,000 lb)
Tire Size ST205 / 75D15 LR-C
Tire Load Rating (ea.) 1,760 lb 657 kg
Wheel Bolt Pattern 5 Lug
No extra fuel cell in this trailer
Fuel Tank Capacity N/A gal N/A L
Fits MQ Power Generator Models DCA36SPXU4F
DCA40SSKU4F2
DCA45SSIU4F
TRLR75XF2 Trailer Dimensions & Weights
Overall Length 147.33 in 3,742 mm
Overall Width 66.25 in 1,657 mm
Overall Height 23.2 in 590 mm
Operating Weight
With Generator Fuel N/Alb N/A kg
Without Fuel N/A lb N/A kg
TRLR75XF2 not included - call for quote.
Trailer Specifications
Gross Vehicle Weight Rating (GVWR) 7,000 lb 3,175 kg
Gross Axle Weight Rating (GAWR) (ea.) 3,500 each lb 1,588 kg
Coupler Rating 3″ Pintle Eye (25,000 lb)
2″ Ball Coupler (10,000 lb)
2-5/16″ Ball Coupler (14,000 lb)
Tire Size ST205 / 75D15 LR-C
Tire Load Rating (ea.) 1,820 lb 826 kg
Wheel Bolt Pattern 5 Lug on 4.5 in
Fuel Tank Capacity 100 gal 378.54 L
Fits MQ Power Generator Models DCA70SSJU4F
DCA70SSIU4F
DCA45SSIU4F
DCA40SSKU4F2
DCA36SPXU4F
DCA25SSIU4F
DCA20SPXU4F
DCA15SPXU4F
DCA10SPXU4C
TLG8SSK4F2
DA7000SSA3
TRLR75XF2 Trailer Dimensions & Weights
Overall Length 151.3 in 3,843 mm
Overall Width 69.3 in 1,760 mm
Overall Height 24.8 in 599 mm
Operating Weight
With Generator Fuel 2,077 lb 942 kg
Without Fuel 1,366 lb 619.6 kg
Option: Generator can be placed on MQ Trailer Models TRLR45 and TRLR75XF2.
Multiquip TRLR75XF2 trailer 100 gallon tank specifications and data sheet.
OPTIONS Call for quote
Water Heater
Battery Charger
Emergency Stop
Low Coolant Level Shutdown
Camlocks
Spring Isolators
Audible Alarm
Trailer mounted $41,583.56 TRLR45 is included in this price!
Emergency Towable Diesel Generators Available Immediately in California.
We have a limited supply of Multiquip Heavy Duty Construction/Emergency Backup Diesel Generators for sale! Your authorized dealer is Mike McPherson call or text 707-332-0703
Due to the fires in Southern California Multiquip has a rapidly dwindling supply of brand new generators available immediately. Brand new models with zero hours. I have been an authorized dealer since 2005. The prices of these generators are the lowest in a decade. Please do not ask for additional discounts. This is the best price available nationwide. All units are on a limited sale. Call or text and place your order to secure your discounted prices 707-332-0703
MQ Power WhisperWatt Super-Silent Generators are built to withstand the toughest jobs no matter how challenging the application. Some of the features include a heavy-duty steel housing, an open delta winding design, and an automatic voltage regulator. Our generators range from 6 kW to 600 kVA and they provide unmatched reliability in portable power.
MQ Power WhisperWatt Super-Silent Single/Three-Phase generators provide reliable power to meet the most demanding requirements. They are designed and built to withstand tough environments at construction sites and provide dependable temporary power at entertainment venues and disaster recovery operations.
Buy it now. This is Multiquip's entire nationwide inventory. Once these are sold out prices will increase a minimum of ten percent, and the lead time will be four to sixteen weeks. Most units will not be replaced until May/June 2025, larger units will not be replaced until September 2025. Call or text Mike 707-332-0703
Generator Models pre-assembled and ready to pickup or ship:
DCA25SSIU4F on a skid no trailer $26,266.46.
On a trailer TRLR25US with a 2 inch ball hitch $ 28,368.59. Blow out sale! Price is as described, additional options are extra.
DCA45SSIU4F on a skid $36,983.52.
On a trailer TRLR45 with 2 inch ball hitch, your best price $ 41,583.47 ea. Price is as described, additional options are extra.
DCA-36SPXU4F $38,374.56, on trailer TRLR45 mounted with 2 inch ball hitch, your best price $42,974.51 ea.
DCA70SSIU4F on a skid $51,299.14, on trailer TRLR70US mounted with 2 inch ball hitch $ 57,265.94 ea.
Customizable Generators with available options:
We also have these emergency diesel generators for sale. The first price shown is a skid mount generator. Options shown are extra to be added to the skid mount price. Example DCA10SPXU4C $15,017.18 + optionable Battery Charger $320.54 = $15,337.72
Single Phase Models:
DCA10SPXU4C $15,017.18 + Trailer TRLRMPXF $2709.50 with extra 28 gallon tank built into trailer + 2 inch ball Hitch $70.00 + Spare Tire $362.88 + Battery Charger $320.54. Hot item. Good for RV, camping trailers and home backup. Super quiet clean power safe for computers.
DCA15SPXU4F $17,587.58 + Trailer TRLRMPXF $2,709.50 with extra 28 gallon tank built into trailer + 2 inch ball Hitch $70.00 + Spare Tire $362.88 + Battery Charger $320.54.
DCA20SPXU4F $26,786.59 + Trailer TRLR25US2 $2,032.13 + 2 Inch ball Hitch $70.00 + 1 set Camlocks $597.63 + Spare Tire $489.89 + Battery Charger $399.17. Hot item. Good for RV, camping trailers and home backup. Super quiet clean power, safe for computers.
DCA36SPXU4F $38,374.56 + Trailer TRLR45 $2,032.13 + 2 inch ball Hitch $70.00 + 1 set Camlocks $556.42 + Spare Tire $350.78 + Battery Charger $399.17. Hot item. Good for RV, camping trailers and home backup. Super quiet clean power, safe for computers.
Three Phase Switchable to Single Phase Models:
DCA25SSIU4F $26,266.00 + Trailer TRLR25US $2,032.19 +2 inch ball Hitch $70.00 + 1 set Camlocks $556.42 + Spare Tire $489.89 + Battery Charger $399.17. Hot item. Good for construction and business backup. Super quiet clean power safe for computers.
DCA40SSIK4F $32,586.62 + Trailer TRLR45USH $4,529.95 + 2 inch ball Hitch $70.00 + 1 set Camlocks $556.42 + Spare Tire $350.78 + Battery Charger $399.17. Hot item. Good for construction and business backup. Super quiet clean power safe for computers.
DCA45SSIU4F $36,983.52 + Trailer TRLR45H $4,529.90 + 2 inch ball Hitch $70.00 + 1 set Camlocks $556.42 + Spare Tire $350.78 + Battery Charger $399.17 + Power Balancer Kit MQPPB45I4F $5,712.00 . Hot item. Good for construction and business backup. Super quiet clean power safe for computers.
DCA70SSIU4F $51,299.14 + Trailer TRLR70US $5,896.80 + 2 inch ball Hitch $70.00+ 1 set Camlocks $556.42 + Spare Tire $393.12 + Battery Charger $399.17 + Power Balancer Kit MQPPBNK70I4F3 $4,771.20. Good for construction and business backup. Super quiet clean power safe for computers.
DCA125SSJU4F $67,701.31 + Trailer TRLR125US $7,983.36 + 2 5/16 inch ball or Pintel . Hitch $80.00 + 2 set Camlocks $1,064.48 + Spare Tire $429.40 + Battery Charger $399.17 + Power Balancer Kit MQPPBNK1254F3 $5,485.20. Good for construction and business backup. Super quiet clean power safe for computers.
DCA150SSJIU4F3 $89,988.19 + Trailer TRLR180EV $10,886.40 + 2 5/16 inch ball or Pintel Hitch $80.00 + 2 set Camlocks $1,064.48 + Spare Tire $501.98 + Battery Charger $1,197.50 + Power Balancer Kit MQPPBNK150I4F3 $5,485.20
DCA180SSJIU4F3 $96,538.18 + Trailer TRLR108EV $10,886.40 + 2 5/16 inch ball or Pintel Hitch $80.00 + 2 set Camlocks $1,064.48 + Spare Tire $501.98 + Battery Charger $1,197.50 + Power Balancer Kit MQPPBNK180J4F3 $6,804.00.
DCA220SSJIU4F3 $108,138.24 + Trailer TRLR220EV $14,261.18 + 2 5/16 inch ball or Pintel Hitch $80.00 + 2 set Camlocks $1,064.48 + Spare Tire $550.37 + Battery Charger $1,197.50 + Power Balancer Kit MQPPBNK220I4F3 $6938.40. Good for construction and business backup. Super quiet clean power safe for computers.
DCA220SSJIU4F3PB 220kVA with Parallel Basler $108,274.32
DCA300SSJU4F3 Series $138,662.50 + Trailer TRLR300EV $13,940.64 + 2 5/16 inch ball or Pintel Hitch $80.00 + 2 set Camlocks $1,06448 + Spare Tire $635.04 + Battery Charger $1,197.50 + Power Balancer Kit MQPPBNKJ4F3 $8,316.00. Good for construction and business backup. Super quiet clean power safe for computers.
DCA300SSJU4F3PB 300kVA with Parallel Basler $152,197.92
DCA400SSI4F3B $182,250.43 + Trailer TRLR400XF3DAE 3 Axles 350 Gallons Electric Brakes $23,345.28 + 2 5/16 inch ball or Pintel Hitch $80.00 + 3 set Camlocks $1,705.08 + Spare Tire $550.37 + Battery Charger $1,197.50 + Power Balancer Kit MQPPBNK400I4F3 $11,466.00.
DCA400SSI4F3BPB $199,257.41 400kVA with Parallel Basler Kit MQPDCS400P required
DCA600SSV4F3B $311,520.38 + Trailer TRLR600XFBP3E 3 Axles 600 gallons Electric Brakes $35,489.44 + 2 5/16 inch ball or Pintel Hitch $80.00 + 4 Set Camlocks $3,447.36 + Power Balancer Kit MQPPB600V4F $9,247.84 + Spare Tire $695.52 + Battery Charger $1,197.50.
DCA600SSV4F3PB $314,671.39 with Parallel Basler Kit MQPDCS600P required
Parallel Basler allow you to parallel the generator in series and add the power together. For example parrallel two DCA400kVA together it makes 800kVA and so on. Paralleling is usually done with the DCA200 thru DCA600. You can also use them in combination.
All units on sale. Call to secure your discounted prices. 707-332-0703
For detailed specifications visit https://www.multiquip.com/multiquip/super-silent.htm
