TITANIUM DOME TWEETERS
These dome drivers have titanium
diaphragms with frequency response to
45kHz. Their small size is ideal for
producing a wide angle stereo sound
image.
INVERTED DOME MIDRANGES
Each midrange driver is 2” in diameter
with a titanium inverted dome. Titanium
has great rigidity resulting in smoother
uncolored reproduction throughout the
critical mid frequencies.
DUAL LD/HP® WOOFERS
Each XRT1K features two Low Distortion/
High Performance 10” custom woofers, augmented with a low velocity top
mounted port. This combination yields
effortless bass down to 20Hz and loads
the listening room from two points so
as to seamlessly blend with the mid and
high frequency array.
THREE SETS OF INPUTS
Three sets of massive gold plated input
connectors make Bi and Tri-amping and
Bi and Tri-wiring a snap.
MID-TWEETER-MID DESIGN
Placing a column of tweeters between
two columns of midranges, wide
horizontal dispersion with controlled
vertical dispersion is realized. This
design projects a wide image and deep
soundstage evenly
Specifications General Specifications
System Driver Complement
Two 10 inch LD/HP Woofers
Forty-four 2 inch Titanium Inverted
Dome Midranges
Twenty-eight 3/4 inch Titanium Dome Tweeters
Impedance
8 ohms Nominal
Frequency Response
16Hz - 45kHz
Sensitivity
88dB (2.8V/1m equivalent)
Crossover Frequencies
250Hz
2,000Hz
Power Handling
1,200 Watts Maximum
Finish Enclosures
High Gloss Black
Finish Grille
Black Knit Cloth with High Gloss Black Trim
Overall Dimensions
Height is 79-1/2 inches (201.9cm) including feet
Width is 14-1/2 inches (36.8cm)
Depth is 15-7/8 inches (40.3cm)
Weight
168 pounds
