Intelligent Paper Cardboard Breaking Strength Testing Machine 056428 - $1,405 (hayward / castro valley)
QR Code Link to This Post
Paper Breaking Strength Testing Machine Intelligent Cardboard Compression Tester 056428
-
Below is our store website link to it:
https://eezglobal.com/newproductdetail.asp?productid=056428&typeid=1866
Product Overview
Cardboard compression tester known as computer monitoring control compression tester, electronic compression tester, is the basic instrument of cardboard / paper compressive strength testing. The tester equipped with various special accessories can do a full range of testing, which includes Ring Crush Testing, Flat Crush testing, Edge Compressive Testing, Adhesive Strength.Testing and other general compression testing, to a variety of materials like paper, packaging materials, etc. It is a multi-functional testing equipment.
Product Parameters
Voltage: AC110V/60Hz
Measurement range: ≤200 kg(441lb)
Accuracy: ± 1%
Unit switch: N, kN, kgf, gf, lbf
Test speed: 0.5"/min
Return speed: 1.2"/min
Upper and lower platen parallelism: < 0.05mm
Pressure plate size: Diameter:4.3"/Φ110 mm(can be customized according to customer requirements)
Up and down pressure plate spacing: 2.4"/60mm(can be customized according to customer requirements)
Resolution ratio: 0.1N
Product size: 14.2"*12.6"*22.8"(36*32*58cm)
Gross weight: 101.8lb(46.2kg)
Product Features & Advantages
-The system automatically calculate RCT, ECT, no need to calculate by user , reduce the workload and error.
-With package stacking test function, can directly set strength, time, after the completion of testing , automatically shut down.
-After the completion of the test , has automatically return function, automatically determine the crushing force and automatically save the test data.
-Can set three speeds ,Liquid crystal display panel , a variety of units can choose.
-Reasonable design, simple use, easy to maintain, strong applicability, significant energy saving effect.
Product Presentation & Details
Item Included 056428
Paperboard/paper tester *1
Printing paper * 1
Auxiliary iron *2
English instruction manual *1
