Short-range molecular distillation apparatus 220531 - $909 (hayward / castro valley)
QR Code Link to This Post
Laboratory short range distillation is a thermal separation process of heat-sensitive products under vacuum conditions. The atmospheric pressure within the system is reduced by the addition of a vacuum, and when the pressure is reduced, the boiling point of the compounds contained will decrease. This process makes the extraction of heavier molecules faster and more efficient. Short residence time and low evaporation temperature will cause small thermal stress on the distillation product. It is designed according to the principle of molecular distillation. Typical applications are polymer organic compounds, chemical pharmaceutical, food health industry, industrial and other fields.
Heating sleeve Parameters:
Capacity (ml):2000
Voltage:110V 60Hz
Power：650W
Temp control（℃）:PID control, inner and outer thermocouple
Working time: continue
Temp range: ambient to 380.
Temp accuracy:±1℃.LED display
Shell material: superfine metal, anti-aging, anti-corrosion
Insulating barrier material: environmental alumina silicate fiber
Upper diameter (mm):180
Exterior dimensions (cm):27.5*19
Net weight (kg):2.93
List:
Smart thermostatic heating sleeve:1(2000ml)
Two distilling bottles:1(2000ml)
Needle distilling head:1(double-deck)
Condenser pipe:1(180ml)
Still head:1(250ml)
Collecting bottle:3(250ml)
Collecting bottle:1(1000ml)
Cold trap:1(120ml)
Thermometer sleeve:1(24#)
Clasp:5(24#)
Clasp:1(29#)
Ball jaw clamp:1(34#)
Triple-grip clip:1(10ml)
Supporting floor:300*350mm
Upright:2(19mm)
Cold trap fixture:1(120mm)
Cold trap support ring:1(100mm)
Cross clamp:3
Item Number: 220531
